19-Pin Female Panel Mount Harness with 12AWG 1' leads
- Availability:
- Usually ships within 2 business days when in stock.
Description
19-Pin female panel mount connector with unterminated 1 feet, 12AWG type MTW wire white and green leads. Wire leads are labeled with identifying pin numbers.
FEATURES
- Fully compatible with Socapex™ "419" and other industry-standard 6-circuit connectors
- Rugged die-cast aluminum backshell and machined aluminum locking ring
- Non-conductive black anodized finish
- Hard gold-plated contacts
CONNECTOR SPECIFICATIONS** (May vary based on manufacturer)
- Gender: Female Panel Mount
- Number of Contacts: 19
- Rated Current / Voltage: 20A 250VAC
- Operating Limit Voltage: 400VAC
- Rated Voltage: 1500VAC
- Color: Black
WIRING SPECIFICATIONS** (May vary based on manufacturer)
- Type: MTW (machine tool wire)
- Size: 12 AWG
- Number of strands: 19
- Conductor material: Copper
- Conductor type: Stranded
- Voltage: 600V
- Length of leads: 12 inches
NOTE: This product may be from VARIOUS MANUFACTURERS. Product may vary slightly from description and pictures.
