Belden KeyConnect Patch Panel 24 Port 1U, Empty

Belden Rack mount Key Connect Patch Panel with twenty four ports. The black unit features a flat front that conveniently fits in a 1U rack space.

Suitable Applications: Compatible with a variety of modules that are suitable for use with Belden IBDN Systems 10GX, 4800, 2400 and 1200.

WHAT'S INCLUDED

• 2 Rear Cable Management Bar
• 1 Management Bar
• 4 Screws (10x32)
• 4 Screws (12x24)
• 1 Label Holder
• 1 Printable Label Flex Half-Sheet
• 2 Velcro Straps
• 1 Installation Guide

SPECIFICATIONS

PHYSICAL

• Number of Ports: 24 Port
• Front Connection: Flush
• Overall Height: 44.450 mm
• Overall Width: 482.600 mm
• Depth: 33.020 mm
• Material: Steel
• Packaging: Individually packaged in a cardboard box.
• Weight: 0.454 kg
• Color: Black

TEMPERATURE RANGE

• Installation Temperature Range: -10°C To +60°C
• Storage Temperature Range: -40°C To +70°C
• Operating Temperature Range: -10°C To +60°C

MECHANICAL CHARACTERISTICS

• Connector System Compatibility: KeyConnect

APPLICABLE ENVIRONMENTAL AND OTHER PROGRAMS

• Environmental Space: Indoor
• EU Directive 2011/65/EU (RoHS2): Yes
• MII Order #39 (China RoHS): EUP 50

FLAMMABILITY, LS0H, TOXICITY TESTING

• Safety Listing: ACA, Bi-national Standard Listed
• Related Parts: Compatible with 10GX, CAT6+ and CAT5E REVConnect and KeyConnect Modular Jacks as well as KeyConnect Multimedia Modules.

NOTE: For proper installation refer to Installation Guide PX104691 included with the product
