ChamSys GeNetix 10-Port DMX Splitter

GeNetix GD10 is a 19" 1U rack-mountable, RDM-capable 10-Port DMX Splitter at home in many different environments, with a design suited for both long-term installations and live events. Two selectable operating modes offer either 1x10 or 2x5 DMX signal distribution. GD10 features an 'RDM Disable button' to strip out RDM data and retime the DMX signal, and its ruggedly built construction includes a PowerCon True1 Mains Input connector.

FEATURES

• GeNetix GD10 10-Port DMX Splitter
• 10 Port RDM E1.20 Compliant DMX Splitter
• 2 Input / 10 Output DMX Splitter
• 1 In to 10 Ouput or 2 In to 5 Output Mode
• 19" 1U Rack Mountable

WHAT'S INCLUDED

• Neutrik powerCON TRUE1 Power Cable: 1

SPECIFICATIONS

HARDWARE

• 5 Pin opto-isolated DMX Output Ports: 10
• 5 Pin DMX Input Ports: 2
• RDM Enable/Disable Option: Yes
• M12 Clamp Fixing: Yes
• Power Input: Neutrik powerCON TRUE1 110 to 240 VAC
• Max Power Consumption (mains): 6.5w

SOFTWARE

• RDM E1.20 Compliant: Yes

WEIGHTS AND DIMENSIONS

• Width: 18.9 in. (480 mm)
• Depth: 8.59 in. (218 mm)
• Height: 1.75 in. (44.4 mm)
• Weight: 6.06 lb (2.75 kg)
