ETC
ETC ColorSource PAR V Zoom LED, Black
- MPN:
- 7421A1010
- Availability:
- This item is shipped directly from the vendor and is subject to their availability.
- Type:
- Par
- Source:
- LED
- IP-Rating:
- IP20
Description
The ETC ColorSource PAR V Zoom is an LED luminaire crafted by lighting experts with a proven history of quality. The manual zoom eliminates the need for additional diffusion and lets you change between spot and wash with a twist of the wrist. With a balanced mix of red, green, blue, indigo, and lime LEDs, and impressive brightness, this will become your new go-to fixture. Add in the features available on all ColorSource V fixtures - Multiverse® wireless, NFC configuration, and next-level brightness - and you have another flexible, workhorse fixture from ETC.
FEATURES
- Five-color array (red, green, blue, indigo, and lime)
- Manual 17–41 degree zoom
- Simple user interface with seven-segment display
- powerCON® TRUE1® TOP connector
- DMX/RDM in and thru (5-pin XLR)
- Multiverse wireless DMX/RDM
- NFC (near field communication) configuration
- LED droop compensation
- Optically calibrated
- Tour-ready, aluminum housing
WHAT'S INCLUDED
- Hanging yoke
- Power cable with connector of choice
SPECIFICATIONS
SOURCE
- LED details: 34 Lumileds LUXEON® C LEDs
- Max lumens: 5,007
- Lumens per watt: 33.4
- L70 rating (hours to 70% output): 54,000 hours*
COLOR
- Colors used: red, green, blue, indigo, lime
- Color temperature range: Color mixing
- Calibrated array: Yes
- Red shift: No
OPTICAL
- Beam angle range: 17-41°
- Aperture size: 7.5 in (190 mm)
- Camera flicker control/Hz range: 5 kHz (default) 25 kHz (via RDM)
CONTROL
- Input method: 5-pin XLR connector
- Protocols: DMX512, RDM, City Theatrical Multiverse, NFC
- Modes (footprint): 5 modes
- RDM configuration: Yes
- UI type: Seven-segment, three-button interface
- Local control: Yes
- Onboard presets: Yes (12)
- Onboard sequences: Yes (5)
- Onboard effects: No
- Fixture-to-fixture control: Yes
- 15-bit virtual dimming engine
WIRELESS
- Band: 2.400–2.480 GHz
- Range: 100 m indoors, 500 m line of sight (subject to conditions)
- Max receivers
- DMX: No limit
- RDM: Varies by transmitter used
- Multiverse SHoW Baby®: 585
- Multiverse Transmitter: 5,000
- Broadcast power: 100 mW
ELECTRICAL
- Voltage range: 100–240 VAC 50/60 Hz
- Input method: AC via powerCON TRUE1 TOP power in and thru
- Inrush (First half-cycle): 120 V 31 A, 240 V 66 A
- Fixtures per circuit : 6 (link up to 5 via power thru connector)
- Wattage typical: 120 V 150 W, 240 V 148 W
- Current draw: 120 V 1.27 A, 240 V 0.70 A
THERMAL
- Ambient operating temp: 0°–40° C (32°–104° F)
- Fan (controllable): Yes (Yes)
- Droop compensation: Yes
- dB range: tbd
- BTUs/hour: 512
PHYSICAL
- Materials: Cast and extruded aluminum
- Exterior housing color: Black
- Mounting options: Yoke
- IP rating: IP20
- Weight: 9.8 lb (4.45 kg)
- Height: in. ( mm)
- Width: in. ( mm)
- Depth: in. ( mm)
INCLUDED ITEMS
- Hanging yoke
- Power cable with connector of choice
WARRANTY
- Fixture 5 years
- LED array 10 years
REGULATORY AND COMPLIANCE
- cETLus Listed
- Conforms to UL 1573 Listed
- Certified to CSA C22.2 No. 166.0 Listed
- CE & UKCA compliant
