JBL Control CRV High Design Loudspeaker

New - open box

High Design Loudspeaker with 70V/100V Transformer. Weather Resistance. Unique, contemporary, curved design. Dual 100 mm (4") woofers provide superb sound quality. Combinable into half-round or full 360° round arc clusters.

FEATURES

• Components: Dual 100 mm (4 in.) woofers and 19 mm (¾ in.) titanium-laminate tweeter
• Outdoor rated to IP-34 (per IEC 529)
• Built-in 70V/100V multi-tap transformer for distributed loudspeaker lines, plus 4 ohm direct capability
• Unique, contemporary, curved design with versatile mounting configurations
• Professional-quality input terminals
• Superb sound quality

The Control CRV brings high design and versatility to commercial applications such as restaurants, retail stores, lounges, theme bars, music cafes, hotels, boardrooms, boutiques, museums, leisure venues, outdoors, upscale lobbies, and other foreground and background music and paging applications that require a fashionable look with superb sound quality.

Dual 100 mm (4") woofers feature Polyplas™ cones for durability, large 32 mm (1½") voice coils wound on vented aluminum formers for high power handling, and dual neodymium magnets for high output with low harmonic distortion. The 19 mm (¾") tweeter features a titaniumlaminate dome tweeter, a shielded neodymium magnet, and Ferrofluid® cooling for maximum power handling and reduced thermal compression. A bi-radial waveguide reduces high frequency variations in the frequency response across the listening area. The advanced high-slope crossover network (36 dB per octave high-pass to the tweeter and 18 dB per octave low-pass to the woofers) provides natural midrange sound quality along with smooth.

SPECIFICATIONS

• Frequency Range (–10dB): 80 Hz – 20 kHz (half-space, on-wall), 60 Hz – 20 kHz (quarter space, at two-wall junction)
• Power Handling:
  • 75 W Continuous Pink Noise, 2 hrs
  • 60 W Continuous Pink Noise, 100 hrs
  • 150 W Continuous Program Power
  • 300 W Continuous Peak Power
• Nominal Sensitivity: 89 dB
• Maximum SPL @ 1m: 108 dB continuous average long-term (peaks of 114 dB)
• Nominal Coverage Angle: 105° horizontal x 80° vertical (2 kHz - 16 kHz, speaker in vertical orientation)
• DI: 8.6 dB (2 kHz - 16 kHz)
• Q 7.4 (2 kHz - 16 kHz),
• Nominal Impedance 4 Ohms
• Minimum Impedance: 4.0 Ohms @ 320 Hz
• Crossover Frequency and Type: 2 kHz – 36dB/octave tweeter; 18dB/octave woofers
• Transformer Taps: 30 W, 15 W, 7.5 W at both 70 V and 100 V (plus 3.8 W at 70 V only) Thru position is 4 ohms

TRANSDUCERS

• Low-Frequency Transducers: Dual 4" (100 mm) PolyPlas,™ shielded woofer with dual neodymium magnets and 32 mm (1.25 in) voice coil on a vented aluminum former.
• High-Frequency Transducer: 3/4" (19 mm) Titanium-laminate dome tweeter, shielded neodymium magnet Ferrofluid® cooling.

PHYSICAL

• Enclosure Material: ABS
• Ports: Screened to protect against ingress of pests
• Environmental: IP-34 rating, per IEC529. Exceeds MilSpec 810 for humidity, salt spray, temperature & UV. Passes Mil-Std-202F for salt spray
• Termination: Screw-down terminal strip, nickel plated metal screws/washers. Accepts up to 9 mm outside 4 mm inside open lug (#6, #8, or #10 lug) plus bare wire up to 12 AWG / 2.5 mm2 .
• Safety Agency Rating: Transformer is UL registered per UL1876.
• Color: Black or white (-WH)
• Dimensions: 364 mm (14.4 in) wide, 251 mm (9.9 in) max depth including wall bracket, 262 mm (10.3 in) side depth, 127 mm (5 in) height
• Net Weight (ea): 3.2 kg (7.0 lbs)
• Included Accessories: Corner/wall-mount bracket with cap, screws, and trim covers
