JSI C21 Dual 20A Non-Dim Relay Power Module

CD80 Non-Dim Power Modules allow existing CD80 and C21 dimmer rack owners to convert existing dimmer circuits to switched power circuits on the fly. These "plug & play" modules are a fast direct conversion for users requiring DMX non-dim control of devices/loads requiring pure sinusoidal AC power. Interchangeable constant and filler modules allow for increased flexibility and versatility.

JSI Non-Dim Power Modules Series Datasheet

FEATURES

• DMX non-dim control of devices/loads requiring pure sinusoidal AC power.
• Designed for use with JSI Manufacturing CD-3000 and CD-2000 Control Systems.
• Available for CD80A, CD80AE, CD80SV (Supervisor) and C21 applications.
• All models feature dual 20 Amp magnetic circuit breakers with a UL 489 rating;
• 277VAC rated 50 Amp tungsten "air-gap" relays.
• Blue control LED indication of relay status activation/closure.
• Up to 10-year warranty available.
• ETL compliant.
