JSI Retrofit Processor Strand C21 installation racks

The CD-3000+ Upgrade Dimming Control System makes expensive replacement of Strand CD80® dimming systems unnecessary.

JSI Manufacturing products are ETL listed and comply fully with UL508 and CSA22.2 No 184 electrical safety approvals. This Internationally recognized safety approval covers the entire assembly specifically for installation into an existing UL approved enclosure (OEM rack) and in no way compromises the electrical safety of the overall system. Official documents available on request.

The CD-3000+ is a next-generation retrofit electronics package designed specifically for Strand/Signify C21 dimmer rack. The CD-3000+ will replace the aging control electronics of the existing dimmer rack making system replacement unnecessary. This UL Listed, full-featured state-of-the-art unit provides a low-cost digital interface to any of today's modern lighting communication protocols.

Designed to install in minutes with only basic hand tools, this elegant package has been designed for longevity and reliability with the end-user in mind. Intuitive LCD user-interface combined with a single modular design makes the CD-3000+ extremely user-friendly and easily serviceable. USB-C Tech Port and Face panel LED's permit easy firmware upgrades and operational status indication.

Full-featured, hi-resolution dimming with a lighting-fast response. Embedded LED lamp curves permit 120VAC line voltage LED dimming with optional Presidor™ LED dimmers delivering unsurpassed LED dimming performance and efficiency. An environmentally and financially responsible solution that installs in a matter of minutes!.

JSI CD 3000+ Series Datasheet

FEATURES

• Replaces the old OEM CD80-C21 with new "next generation" control electronics. Upgrade any vintage CD80® rack in minutes.
• Processor reverse compatibility with all existing CD-3000 systems.
• Modular design with a single "plug-in" module.
• Compatible with OEM dimmer rack wiring for fast easy installation.
• USB-C Bootloader permits ease of onsite firmware upgrades.
• 96 Hi-resolution digital outputs with individual dimmer profile selection.
• Dual opto-isolated DMX512 inputs.
• Optional Ethernet node supports a wide range of communication protocols.
• Analog and dedicated dry contact BMS inputs for interface with HVAC, security, and fire alarms.
• "Load Shed" inputs for power management and photocell interface.
• LCD user interface for ease of set up and monitoring. Site programmable via a user-friendly, intuitive, and self-prompting menu structure. No laptop computer or special software is required!
• Dimmer rack thermal shutdown protection.
• Removable memory dongle permits remote/off site backup of configuration data and fast "swapping" of Processor modules. Ease of future firmware upgrades.
