JSI Universal 19" 3RU w/ 96 PWM outputs

The CD-3000+ Upgrade Dimming Control System makes expensive replacement of Strand CD80® dimming systems unnecessary.

A 19" rack mount version of the CD-3000+ provides a universal brain transplant for virtually anyone’s aging dimmer rack that utilizes pulse width modulation (PWM) for forward phase control of standard solid-state relay (SSR) driven dimmers. Contains all standard CD-3000+ features including dual DMX inputs, optional ethernet input, analog inputs, dry contact inputs and more. Measuring only 3 RU’s in height, this unit will control up to 96 dimmers via terminal block or RJ45 connector for ease of remote wiring between the CD-3000+ and the dimmer rack. An optional 4RU wall mount enclosure is available for a fast, low-profile professional installation.

JSI CD 3000+ Series Datasheet

FEATURES

• CD-3000+ Control System designed for 19" rack installations.
• Slim design is only 3RU in height.
• Dual DMX inputs with optional ethernet input.
• 96 PWM dimmer drive outputs configurable for either positive or negative control of phase controllable SSR's.
• Interface via "Phoenix" style terminal block or RJ45 connector.
• Optional low-profile 19" wall mount rack.
