Luminex LumiNode 2
- MPN:
- LU0100070
- Availability:
- Usually ships within 2 business days when in stock.
Frequently bought together:
Description
LumiNode 2 is specifically designed with an all metal, robust enclosure, to mount on a fly bar or a wall, making it an ideal solution for theatre- and studio AV installs or for use at live performances.
Equipped with 2x 1Gb Ethercon ports and 2x 5-pin DMX ports LumiNode 2 offers flexibility in a small package. Each DMX port is fully optically and galvanically isolated and can be configured as an in- or output.
All relevant industry standard protocols such as Art-Net, sACN, KiNET, RTTRpl (Blacktrax) are supported and can be processed and converted by the 4 onboard process engines supporting HTP, LTP, Crossfade, Backup, Switch and Custom merging modes with soft patch functionality.
FEATURES
- The ideal Ethernet/DMX processing device for touring, mounted in the truss or in a rack.
- Half 19" rack or truss mountable.
- All relevant industry – standard protocols such as Art-Net, sACN, KiNET, RTTrPL (Blacktrax) are supported.
- Intuitive UI – Process engines can be easily configured in a very intuitive workflow.
- Advanced networking – Use the full capacity of the Gigabit connectivity by sending different data in a different Group (VLAN)
- Integration with web API – unit ideal for integration and automation in installation projects.
SPECIFICATIONS
CONNECTIVITY- DMX/RDM: 42x Neutrik 5 pin XLR (female) shielded & gold plated
- Network: 2x Neutrik 5 pin XLR (female) shielded & gold plated
- Contact Closure: 1x 2-pin pluggable terminal block
- Power: PoE-802.3af (Class 0)
- Supported protocols: DMX512 (1986 & 1990), DMX512-A, RDM ANSI E1.20-2010
- DMX port direction: Input or output (configurable)
- DMX port isolation: Optical and galvanic isolation per port
- DMX timing: Framerate: 10-40fps, Break: 176-352µs
- Supported protocols
- Art-NetTM (1-4)
- sACN ANSI E1.31-2018
- RTTrPL (BlackTraX)
- KiNET v1, v2
- Port speed: 10/100/1000Mbps
- Port sensing: Auto-negotiation, MDI / MDIX
- Split management interface: Yes
- Groups (VLAN) support: No
- Processing engine: 4
- Merging: Yes (HTP, LTP, X-Fade, Backup, Switch, Custom)
- Softpatch: Yes
- Master/Limit: Yes
- Trigger system: Yes
- Reroute function: Yes
- Profile manager: Yes
- Snapshot: Yes
- Monitoring Software: LumiNet Monitor, Araneo
- DMX redundancy: Yes
- Display & jog: Yes
- Ethernet port connection: link/activity LED, Group RGB LED
- DMX port: DMX/RDM RGB LED
- Power input: PoE 802.3af (Class 0)
- Power consumption: Max 8.5
- Power redundancy: No
- Configuration: Built in Web server, Documented Web API
- Operating temperature: 0 to +50°C
- Storage temperature: -10 to +70°C
- Humidity(non condensing): 5 to 95% RH
- Enclosure: Robust all metal housing
- Dimensions (W x D x H): 158 x 146 x 50.5 mm
- Weight: 0.9 kg
- Mounting type: Truss mount, Wall mount
- Packaging: 240 x 230 x 80 mm
- Electromagnetic emissions and immunity
- EN55032 class A
- EN55035
- EN61000-3-2
- EN61000-3-3
- EN61000-4-2
- EN61000-4-4
- EN61000-4-5
- EN61000-4-6
- EN61000-4-8
- EN61000-4-11
- FCC Part 15 CFR 47 class A
- ICES-003 Issue 6
- Safety approvals
- IEC 62368-1
- EN 62368-1
- UL 62368-1
- CAN/CSA-C22.2 No. 62368-1
- CE
- Green
- RoHS
- REACH
