ProPlex GBS EZ-LAN Unity 18 PoE

EZ-LAN makes today’s complex show networking easier and accessible for everyone. These simple to operate yet powerful Gigabit Ethernet switches distribute up to five discrete networks – lighting, audio, content, server, console, or communications – quickly, effortlessly, and simultaneously. Users untrained in the complexities of managed networking can easily isolate networks and access and change VLAN assignments with a single button press.

With 14 ports, assignable in up to five separate groups, EZ-LAN is a revolutionary addition to the ProPlex Data Distribution range of multiple format data management systems, all designed and built to withstand "Life on the Road."

FEATURES

• EZ-User configurable, high-throughput Gigabit Switch
• Simultaneously separate and distribute up to five discrete networks – e.g lighting, audio, media, content, console, communications – with a few button presses
• Two EZ-LANs do the work of up to 10 unmanaged Gigabit switches
• 14 LAN ports in two- and four-port groups, assignable to up to five VLANs
• 14 EtherCON LAN ports, 2 EtherCON Trunk ports, 2 OpticalCON Trunk ports (QUAD Standard. DUO optional)
• Add a second fibre or copper connection for automatic redundancy and twice the speed
• Compatible with a wide range of entertainment-specific protocols, including AES67, ArtNet, Dante, GreenGo, HippoNet, HogNet, Livewire, MA-Net 2/3, Q-LAN, RAVENNA, RDMNet, sACN, and more!

ProPlex EZ-LAN Unity18 LTR Datasheet

SPECIFICATIONS

• Part Number: PPEZLPOE2Q16R
• Base TX 10/100/1000 Ports: 16
• Fiber Optic Link Ports: 2
• Optical Connectors: Neutrik OpticalCON QUAD (DUO option available)
• Ethernet Connectors: Neutrik EtherCON RJ45
• AC Power: 100-240V, 50/60Hz
• Power Connector: Neutrik PowerCON TRUE1 IN/THRU
• Number of Ports with PoE: 8
• PoE type: "PoE+" (25W) also compatible with "PoE" (15W) devices
• PoE standards: 802.3af and 802.3at
• Max unit power consumption: 270W
• Color LCD display: Yes, 1.8"
• Custom switch configurations: Yes, via LCD menu
• Port status LEDs: RGB multicolor
• Operating Temperature: -20°C to +40°C
• EIA Rack Units: 19" 2U
• Unit Dimensions (WxHxD): 6.3 x 10.3 x 2.9 in. (159.8 x 263.3 x 73.2 mm)
• Weight: 11.8 lbs (5.3 kg)
